Eagle’s stainless steel countertops are a perfect finishing complement to our line of stainless steel inset casework.
- 16 or 14 gauge, type 304 or 316 stainless steel. Other gauges and types of stainless available to meet the function and chemical resistant demands of highly specialized labs.
- Standard front edge Square or Box Marine, unless otherwise specified.
- Back and end splashes are manufactured per specification.
- All working surfaces and sink bowls have coved sanitary horizontal and vertical corners.
- Either a mechanical hairline seam or field welded joint available per your specifications. Maximum length without seam is 144˝ if no end splash. Length is reduced by 51⁄2˝ for each end splash that may be required.
- Fabricated sink bowls available in most any size and depth with single or multiple compartments.
- For backsplash mounted faucets, splash will need to be at least 2˝ deep for plumbing access, holes for deck mounted faucets are typically centered 11⁄2˝ from the edge of sink bowl.
- Both L-shaped and U-shaped tops are available per your drawings. Corners are mitered and factory welded. Maximum size without field joint provisions is 96˝ x 96˝ to fit into standard trailer for ground shipment.
- Countertops have stainless steel reinforcing hat channels. Sound deadening tape is factory installed. Top support options include National Sanitation Foundation (NSF)-listed sprayed latex sound deadening and marine grade plywood backing with white laminate facing.
- Standard packaging is wood reinforced cardboard and is included in the cost. Should full crating be required, it too will be included in the cost.
One-Compartment Utility Sinks
Feature bullnosed front edge design, all 16 gauge stainless steel construction with rolled rim partition. Entire assembly is fuse welded and planished, providing a one-piece seamless sink unit. For numerous applications when NSF construction is not required. For sink with no drainboards, optional detachable drainboards are available. IN STOCK. READY TO SHIP NOW!
Electronic Drive Adjustable Height Tables
Enhance productivity and comfort for everyone! Electronic Drive Adjustable Height Tables have an adjustable height from 29˝ to 40˝ and 2˝ square legs with leveling mounts. Heavy gauge corner angles are welded to the legs and tapped for bolting on 5˝ high aprons. Synchronized electromechanical drive in each leg provides for height adjustment. Maximum table…
Eagle Group Wire Shelving Starter Units
Eagle Group wire shelving has a Patented QuadTruss® design, with mat wires welded to a four-truss assembly on front and back, and a three-truss assembly on each end. Below are just a few reasons why Eagle Group wire shelving is the way to go: Patented QuadTruss® design (patent #5,390,803) makes EAGLE shelves up to 25%…
Product Spotlight! Vertical Storage Cabinets
All stainless steel type 304 enclosed cabinet. Four adjustable shelves, 18″ or 24″-deep by 36″- or 48″-long. Available with sloped top for laminar flow. Available as Stationary or Mobile Custom sizes available. Spec Sheet
Continue Reading Product Spotlight! Vertical Storage Cabinets
Polytech High School’s Welding Class!
Students had the opportunity to observe the welding process from start to finish, learning about the steps and techniques involved. They also saw different types of welding in action, such as MIG and TIG welding, as well as the safety measures taken to ensure a safe working environment.The students were able to ask questions to…
May the Fourth be with you!
From a galaxy far far away….May the 4th Be With You. Happy Star Wars Day!We had a few employees show up today dressed for the occasion.
